| Categories | RJ45 Keystone Module |
|---|---|
| Brand Name: | WONTERM |
| Model Number: | WTKJ |
| Certification: | CE/FCC/UL/ROHS |
| Place of Origin: | China |
| MOQ: | 1000pcs |
| Price: | negotiation |
| Payment Terms: | T/T or western Union |
| Supply Ability: | 30000pcs per month |
| Delivery Time: | 10 working days after received your payment |
| Packaging Details: | 250m/box |
| HS Code: | 8517709000 |
| Gold Plated: | 6μ |
| Installation Mode: | Rotary Jack |
| Shape: | Rectangular |
| Color: | White |
| Delivery Detail: | 3 days |
| Material: | Plastic,Gold |
UTP Keystone Module 8P8C gold plated Unshielded CAT5E Keystone Jack Network Connector Fluke Test
Specifications:
| MATERIAL | KEYSTONE JACK HOUSING: ABS+PC, UL 94-V0, WITH OPTIONAL COLOR. |
| CONTACT BRACKET: PBT+GLASS FIBER, UL 94-V0, WITH BLACK COLOR. | |
| JACK CONTACT MATERIAL : PHOSPHOR BRONZE WITH NICKEL PLATED. | |
| JACK CONTACT FINISH : 50 MICRO-INCH GOLD PLATE ON PLUG CONTACT AREA. | |
| IDC HOUSING:PC+GLASS FIBER, GREY COLOR(RAL7035), UL 94-V2 | |
| IDC TERMINAL:PHOSPHOR BRONZE WITH TIN PLATED. | |
| PCB:FR-4, UL 94-V0 | |
| PERFORMANCE | T568A & T568B WIRING. |
| INSERTION FORCE: 20N max. (IEC 60603-7-5). | |
| RETENTION STRENGTH : 7.7KG BETWEEN JACK AND PLUG. | |
| JACK LIFE : 750 CYCLES MIN (ISO/IEC 11801, ANSI/TIA 568 C.2) | |
| IDC: SUITABLE FOR 23-26 AWG STRANDED AND SOLID WIRE, COMPATIBLE WITH 110 PUNCH DOWN TOOL | |
| OPERATING TEMPERATURE RANGE : -10 C TO 60 C. | |
| STORAGE TEMPERATURE RANGE : -40 C TO 68 C. | |
| THE CAT.6 TRANSMISSION PERFORMANCE IS IN COMPLIANCE WITH THE ANSI/TIA 568 C.2 STANDARD. |
Description :
WONTERM Cat5E Keystone jack from EXW provide ultimate performance and durability, no matter what if they are used in a home network installation or being used to build up the largest data center, these Keystone jack will live up to the expectations time and time again.
With our CAT5E total solution products applying with patch panels, keystone jacks, outlets, patch cords and verified cables, the performance could fulfill your high speed transmission requirements from telecommunication room to work area. Also, our products are all certified by UL and compliant with RoHS.
| MOQ | 1000PCS |
| Payment terms | T/T,Paypal(30% deposit before production,70% before shipment can be accepted) |
| Price | FOB |
| Delivery | 2-3 weeks |
| Pacing | 1pcs/plastic bag,100pcs/box,1000pcs/CTN,CTN Size:46*26*21 |
| Production capacity | 500000/month |
|
