Mingtech Free Standing Consumption-type Machines sample , Ticket Vending Kiosk i3 LGA1155

Categories Free Standing Touch Screen Kiosk
Brand Name: Mingtech
Model Number: MT9
Certification: Contact PBOC3.0 L1,Contactless PBOC3.0 L1,Contact EMV L1,Contactless EMV L1,CE,FCC,RHOS
Place of Origin: China
MOQ: 2
Price: negotiate
Delivery Time: 10-25days
Supply Ability: 1300 sets per days
Payment Terms: T/T, PayPal, Western Union, D/P, CommBank.
Size: 665mm*500mm*1680mm
Color: Any Pantone standard.
CPU: i3 LGA1155 CPU
Extra function add on: Yes
Variants: On-wall/ free stand
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Mingtech Free Standing Consumption-type Machines sample , Ticket Vending Kiosk i3 LGA1155

Self-serve Movie-tickets vending kiosks with barcode scanning function. (Card payment system include)


Specifications
ModularParameter
Mother boardInterl H61 industrial i3 LGA1155 CPU, DDR3 1600MHz 4GB memory. SSd MSATA 128GB. Realtek RTL8111E Gigabit-NIC. Wakeup on LAN function . Intergrated ALC662 audio card.Single ethernet interface,single LVDS interface, single VGA interface, 6 COM slots, 8 USB interfaces, single MINIPCIE interface, single MINI SATA interface. WCDMA available.Intelligent temperature control fans function.
Monitor32 inch capacitive touch screen AIO,display ratio 4:3,water proof, anti-explosion,dust-proof,luminance 250cd/m2,contract ratio 1000:1,resulotion:1280×1024@60Hz,screen hardness 7H,touching respond time <10ms, multidirection touch available.VGA slot.
Card Readercontact:ISO7816 Atype 5V/B type,3V/C type standard. card 1.8,4442,4428.
contactless:Standard ISO14443 Type,S50/S70/CPU/MIFARE
magnetic stripe: ISO7810/7811 standard. Magnetic card 1, 2, 3 track read. Frequency:13.56MHz±7KHz. Serial connection interface.
Barcode readerUSB interface,Scanning function :two-dimensional image (838 x 640 pixel),PDF417 two-dimensional available, Datamatrix two-diemsional barcode ,QR Code,GM Code,the reader enable paper note,LCD,phone screen etc. any barcode from those medium to be detected. Working Temp: -30°C~70°C. Element Size:65mm*61.2mm*28.7mm.
UPS600VA, 300W. input voltage:140~295VAC; frequence:46.5Hz-53.5Hz. Output voltage: 220VAC±15%; output voltage:50±1Hz..
Build-in Thermal printerLine thermal printer,print density 8 dots/mm,speed 150 mm/s(MAX),reciept wide 80mm,printing character: ASCII/GB18030/multinational character set,DC12V/2A,RS-232 communication interface,black label detection,paper out indicator(Neop),anti-paper jamming. Paper wide: 80mm. Scroll diameter:150mm.
Audio& subtitleMultilanguage translate available. Online upgrade.

Applicable Field:


Business Organizations: Supermarket, large-scale shopping malls, exclusive agency, chain shops, large-scale sales, star-rated hotels, restaurants, travel agencies, pharmacy.


Financial Organizations: negotiable securities, funds, insurance companies, pawnshops;


Non-profit Organizations: Telecommunications, post offices, hospital, schools;


Public Places: Subway, airports, stations, gas stations, toll stations, bookstores, parks, exhibition halls, stadiums, museums, convention centers, ticket agencies, HR market, lottery centers;


Real Estate Property: Apartments, villas, offices, commercial buildings, model rooms, property brokers;


Entertainments: Movie theaters, fitness halls, country clubs, clubs, massage rooms, bars, cafes, Internet bars, beauty shops, golf course
