| Categories | Barcode Scanner Module |
|---|---|
| Brand Name: | Rakinda |
| Model Number: | LV12 |
| Certification: | CE/ROHS/FCC |
| Place of Origin: | China |
| MOQ: | 1 |
| Price: | USD+30-45$+1pcs |
| Payment Terms: | T/T, Paypal, Credit card |
| Supply Ability: | 1000+pcs+per week |
| Packaging Details: | Paper Carton package |
| Product Name: | 1D Barcode Scanner Module |
| image sensor: | Linear CCD sensor |
| Decode Rate: | 200 decodes/sec (default) |
| Interface: | TTL232/USB/RS232 |
| Light source: | 632nm visible red light |
| Depth of field: | 3-70cm |
| Work Voltage: | DC3.3V-5V |
| Dimensions: | (L) 32.2 x (W) 44.15 x (H) 20mm |
Raspberry Pi 1D CCD OEM Barcode Scanner Module Reading EAN JAN UPC
Low Cost Raspberry Pi 1D CCD OEM Barcode Scanner Module Reading EAN/JAN/UPC
LV12 barcode scanner description:
LV12 is a sort of utilitarian embedded barcode reading engine. Applying to Computerized CCD
Image Recognition System, it ensures the fast scanning and decoding accuracy on popular 1D barcodes.
LV12 Scanner engine main features:
LV12 Scanner Engine Application scenarios:
Traditional self-service devices, like kiosk or vending machines.
Compatible OS: Android, Windows, Linux
LV12 scanner module Parameters:
| Product name | 1D barcode scanner module |
| Item number | LV12 |
| Interface | RS232/ USB/ KB |
| Image Sensor | Linear CCD Sensor |
| Processor Type | C8051 compatible |
| Operating Freq. | 24.5 MHz (Internal) |
| Scan Rate | 100 scans/sec ±10% |
| Reading Distance | 230mm@20mil/0.5mm, PCS90% |
| Print Contrast Ratio | PCS45%@4mil/0.1mm |
| Resolution | 5mil/0.127mm@PCS90% |
| Reading Angle | Test Conditions : Code 39, 10mil/0.25mm, PCS90% |
| Pitch Angle | 5°~70° (±5°) |
| Skew Tolerance | 5°~60° (±5°) |
| Light Source | Visible Red light 632nm LED |
| Ambient Light | 5000 Lux Max. |
| Weight | 17g |
| Dimensions | 44(W)mm*30(D)mm*19.2(H)mm |
| Operating Temperature | 0 ℃ to + 50 ℃ |
| Storage Temperature | -20 ℃ to + 70 ℃ |
| Relative Humidity | 20% - 95% ( non-condensing ) |
| Decode Capability | EAN-8, EAN-13, Codabar, CODE11, CODE 39, CODE 93, CODE128,China Post, GS1-128, GS1 Limited, GS1 Omnidirectional, UPC-A, UPC-E, ISBN/ISSN, ISBT , Interleaved 2 of 5, Matrix 2 of 5, Industrial 2 of 5, MSI, Plessey, ITF14. |
| Environmental parameters | |
| Operating Temperature | -20℃ to 50℃ |
| Storage Temperature | -40℃ to 70℃ |
| Relative humidity | 5% to 95%(Non-condensing) |
| Drop test | 1.2meter,100times |
Company Advantages:
Our company is specialized in barcode scanner for 20 years since 2000, we have professional research
developement team, has our own factory, support OEM design. We have many customers from different
countries already. And we are Gold supplier in the Alibaba. Our product is certificated by CE,ROHS and FCC.
FAQ:
Q1: Can I get some samples? Are they free?
A1: We support 1-2pcs sample order. Samples should be paid.
Q2: How can I buy?
A2: We are trade assurance supplier at Alibaba. You can start
online order directly. Or pls contact us directly
according to the contact info. We will send you proper link directly.
Q3: What is your payment method?
A3: We accept Alibaba online orders by Credit card, PayPal ,T /T
Q4: How long is your warranty time?
A4: Our officially promised warranty time is 1 year after delivery.
Q5: Where can we download the user manual of the scanners?
A5: We will send by email after you get samples.
Q6: What's the lead time?
A6: For sample, it is typically within 5-7days by DHL. For bulk
order, it depends on quantity and model you order.
Q7: Can you provide OEM service?
A7: Yes. We need further discuss about details.
|
