Self Cleaning Trommel Rotary Screen for Sieving 80 Mesh Crystalline Flake Graphite Powder

Categories Magnetic Separator machine
Applicable Industries: Energy & Mining
Showroom Location: None
Condition: New
Type: Gravity Separator
Production Capacity: Varies
Place of Origin: Shandong, China
Brand Name: guote
Voltage: 380V
Dimension(L*W*H): 2600*1400*1700mm
Weight: 2200 KG
Warranty: 1 Year
Marketing Type: Ordinary Product
Machinery Test Report: Provided
Video outgoing-inspection: Provided
Warranty of core components: 1 Year
Core Components: Bearing, Motor, PLC
Key Selling Points: Automatic
Product name: Trommel Screen
Application: Ores Stone Sands
Capacity: 1-10t/h
Screen size: 0-0.1mm
Usage: Mining Concentration
Spare parts supply: Lifelong Provide
Color: Customizable
After-sale service: Timely Solutions
Quality: High-level
Certification: ISO9001,CE
Packaging Details: Containers or according to customer requirements
Port: qingdao
Supply Ability: 100 Set/Sets per Month
Price: $4,988.00/sets 1-4 sets
MOQ: 1 set
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Self Cleaning Trommel Rotary Screen for Sieving 80 Mesh Crystalline Flake Graphite Powder

Product Description

Trommel screen is also named drum screen, whic is consist of four parts: drum, undersize hopper, support base, drive device.

When material feed into the drum, under the influence of large centrifugal force, material will make a sprial movement along with drum surface. Meanwhile, oversize materials was removed out of discharge outlet; qualified materials(different sizes) be collected in undersize hoppers. Then sent to be the next system by belt conveyor or other.

Technical Features

Trommels are designed for high performance screening, classification and grading application. With over 50 years experience of it, our trommel screen has the following features:

  1. Good performance, highest production rates, lowest input costs and long service life.
  2. Capacity range of 7.5-1500 m3/hour of slurry, or 6-600 tons/hour of solids, per single trommel.
  3. Speical design of screen makes it more durable than a common one.
  4. Heavy duty jacking and adjustable stands, assist in rapid set up & assembly time.
  5. High pressure spray bar network around the hopper and through out the length of the trommel.
  6. Heavy duty roller supports (steel or rubber) wheels.
  7. Portable mobile or stationary configuration.
Application

1) Quarry: gravel, clay, mountain meal, sand, etc.

2) Coal Industry: lump coal, coal dust, coal washing, etc.

3) Cold Mine: gold screening and washing

4) Chemical Industry: sifting calcium oxide, compost

5) Metallurgy, construction, mineral-selecting, etc.

6) Recycling Industy: solid waste, scrap tires, plastic, etc.

Technical Data
