Automatic CNC mode Engine block cracks non-destructive testing X ray machine Unicomp UNC320

Dynamic Precise Casting Part Inspection Real Time X-ray Image System

The UNC320 is the newest standard system. Whether you are inspecting small or large components, the UNC320 is the best option for customers needing a compact system with unique capabilities generally available on a larger X-ray or CT system.

X-RAY SOURCE

Micro-focus X-ray tube

Voltage Range: 320 kV

Minimum Focal Spot Size: ~5 microns

MANIPULATOR

Maximum Sample Weight: 150kg

SYSTEM CAPABILITIES

Advanced 2D X-ray inspection

Overall Maximum System Resolution: ~5 microns

50cm diameter x 80cm tall nominal part envelope

Comprehensive acquisition, processing and archival program with user-friendly interface

High performance image processing and measurement functions

Non-proprietary multiple image format

CABINET

External Dimension: 2290mm*1604mm*2598mm(L*W*H)

Cabinet Features: interior lighting, sliding access door, leaded glass viewing window

Exact specifications vary depending on tube, detector, and other optional configurations.

Our industrial solutions have a wide range of advantages

1. Sophisticated proprietary image analyzing algorithms which allow to realize reliable automatic detection systems of non-conformities.

2. Statistics, computer assisted measurement, post-analysis, remote workstations, archiving, integration into customer’s network and production management systems.

3. Modular design, broad range of accessories and options for maximum compliance with customer’s production and quality assurance processes

4. Flexibility and compact design our industrial installations can be adopt into the most manufacturing chains in combination with operator or automatic control.

5. Ultra low radiation dose is an effective solution for scanning different automotive parts loaded on the hanging conveyor line.

X-RAY DETECTOR

Digital X-ray detector types: Flat Panel

Grade Options: Standard, Premium,

Detector Size: up to 50 cm x 80 cm

X-ray Intelligent Detection System Integrator (Testing Equipment + Industrial Cloud Tracking System)

Shenzhen Unicomp Technology was incorporated in 2002. It is a national-level high-tech enterprise which involved in the R&D and manufacturing of X-ray technology and intelligent detection equipment. Unicomp has become the leading enterprise in world wide X-ray industry. This technology is widely applied in Public Security, EV Lithium battery,SMT PCBA EMS, IC, Semiconductor, Solar Photovoltaic, LED, Connector, Automotive Casting Parts, Wheel, Tires, Pipe welding, Food and Beverage, Pressure vessel industry etc.

Unicomp Technology has a dedicated pool of local and foreign senior professional R&D engineers with extensive experience in high-level science and technology. The company is undertaking major national special project (namely “02” project and “863” project) and X-ray detecting equipment R&D in new fields of application. It also works closely with The Chinese academy of sciences, Tsinghua University, etc. to advance the core technology of X-ray imaging. Presently Unicomp has submitted a total of 432 patents with 319 authorized. Unicomp has obtained numerous management system certifications, such as ISO 9001 quality management system, ISO 14001 environmental management system, OHSAS18001 occupational health & safety management system, as well as ISO27001 information safety management system.

Today, Unicomp Technology has three R&D /Manufacturing sites exceeding 60,000㎡ respectively located at Wuxi/Jiangsu Province, Shenzhen/Guangdong Province, and Chongqing. Our sales and service centers are located all across China including Beijing, Shenyang, Tianjin, Xi'an, Qingdao, Wuhan, Chengdu, Ningbo, Xiamen and etc. The company has also penetrated into the international market with sales and service support in the USA, Canada, Mexico, Brazil, Germany, United Kingdom, France, Italy, Spain, Australia, Hungary, Romania, Russia, Poland, Uzbekistan, South Africa, Morocco, Tunisia, Turkey, UAE, India, Singapore, Malaysia, Thailand, Vietnam, Philippines, Taiwan, Hong Kong. This international connection has helped Unicomp to be recognized as a Global Force in today’s X-ray industry. Today “UNICOMP” is a hallmark brand in the industry both at home and abroad.

Unicomp Technology upholds its Integrity, Deploitation, and Excellence in the business is committed to meeting the highest level of International Standards and promises to be a responsive partner with all of our customers. This philosophy has enabled Unicomp to generated a strong Global customer base of many International Renowned companies including Flextronics, Foxconn, JABIL, Elcoteq, Philips, GM, Bosch, TRW, Delphi, ABB, Continental, Creation technologies, Salcomp, Selcom, Computime, Emerson, LEAR, V.S. Industy, Microtronics, SVI, Toshiba, NEC, Canon, Olympus, OMRON, SANYO, Fujitsu, Honda Lock, Samsung, LG, Amphenol, Littelfuse, Murata, KEMET, ROHM, Hybrionic, Cooper, ELRAD, Sumida, ELDOR, USI, Inventec, AELTA, PRIVAX, LITEON, Sensata, LuXshare, LENS, AAC Technologies, SANGSHIN ELECOM, Hisense, Skyworth, KONKA, TCL, ZTE, CHANGHONG, WINGTEC, DBG, BYD, VIVO, HIKVISION, GOOD-ARK, DESAY SV, CATL, Panasonic, Sony, Boston Power, BAK, GUOXUAN HIGH-TECH, Sunwoda, Coslight, TENPOWER, BMW, Tesla, Audi, CHANGAN, DONGFENG Motor, Honda, EATON, Turkey MMS, SF Express just to name a few.
