| Categories | Force Testing Instruments |
|---|---|
| Brand Name: | AISRY |
| Model Number: | ASR-2T |
| Certification: | ISO |
| Place of Origin: | China |
| MOQ: | 1 set |
| Price: | Negotiable |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 200 sets per month |
| Delivery Time: | 15 work days |
| Packaging Details: | Standard export wooden case |
| Maxium load: | 2000KG |
| Accuracy level: | 0.5 level |
| Power consumption: | 0.4 kw/A |
| Force accuracy: | indicating±0.5% |
| Effective force range: | 0.4%~100%(0.5level) |
| Warranty: | 1 Year |
| Power supply: | 220V/50HZ |
| Effectively stretch the space: | 0.01~500mm/min |
Computer System Universal Material Tensile Testing Machine Force Testing Instruments
Application :
This Machine is widely used in aviation, aerospace, petroleum chemical industry, machinery, metal materials and products, electric wire and cable, paper, printing and packaging, tape, bags handbags, textile fiber, pharmaceutical, food industry, etc. Testing for all kinds of materials and the physical properties of the products, semi-finished products, the choose and buy all kinds of different furniture can do tensile and compressive, the pull, bending, tear, peel, adhesion, shear test and etc.
parameter:
| Maxium load | 2000KG(Can be customized) |
| Accuracy level | 0.5 level |
| Effective force range | 0.4%~100%(0.5level) |
| Force accuracy | indicating±0.5% |
| Testing machine resolution | the maximum load is 1/200000,internal and external undivided,and the entire resolution is unchanged |
| Load sensor | Basic configuration:pull,pressure sensor(maximum load)one extended configuration:can be equipped with multiple sensors |
| Extended configuration | 400mm(can be widened according to customer requirements) |
| Effective test width | 800mm(can be widened according to customer requirements) |
| Effectively stretch the space | 0.01~500mm/min |
| Test speed range | indicating±0.5% |
| Displacement measurement accuracy | indicating±0.5%(according to customer requirements matching large deformation or samll deformation) |
| Deformation measurement accuracy | Electric limit protection |
| Test bench lifting device | Fast/slow speed automatic control,adjustable point |
| Test bench return function | Manual or automatic two options,automatic or manual at the end of the test to return the initial position at maximum speed |
| Overload protection | More than 10% maximum load,automatic machine protection |
| Fixture configration | Stretching fixtures a set |
| Host size | 900*600*200mm |
| Power system | Servo motor + high precision ball screw rod |
| Power supply | 220v/50HZ |
| Power | 1.5KW(Accroding to different force value requirements, standard with different power motor) |
| Host weight | about 400kg |
|
