| Categories | Branch Circuit Monitoring |
|---|---|
| Model Number: | PZ-K8 |
| Place of Origin: | Jiangsu, China |
| Brand Name: | Acrel |
| Supply Ability: | 1000 Piece/Pieces per Week |
| Packaging Details: | paper carton |
| MOQ: | 1 Piece/Pieces |
| Iutputs: | 16 switch signals |
| Communication port: | RS485(Modbus RTU) |
| SOE capacity: | 1600 sets |
| Dimensions: | 50*110*160mm |
| Installation: | standard din rail TS35mm |
| Port: | Shanghai |
| Company Info. |
| Jiangsu Acrel Electrical Manufacturing Co., LTD. |
| Verified Supplier |
| View Contact Details |
| Product List |
1. Genera
RTU Unit Is an intelligent component for high performance power distribution with application in fields such as intelligent power distribution, industrial automation and the like. The product includes three units: Remote Control Unit, Remote Switche state monitoring Unit and Remote Measuring Unit.
2.Technical Features
Remote Switches state monitoring Unit
| Technical Parameters | PZ-K8 |
| Inputs | 8 switch signals |
| Inputs method | Active wet contact(DC12V) or passive dry contact |
| Communication port | RS485 (Modbus RTU) |
| Bus capacity | ≤32 |
Resolution of switching state | Distinguishing capability for bit changing in succession of multiple contacts.When the bit changing interval of any two contacts is more than 1ms,the distinguishing capability (less than 2ms) of the unit is reflected in SOE |
Data update cycle | for all channels : 1ms |
Debouncing time in remote communication | Debouncing time is 1~99ms (settable) for all channels |
| capacity(SOE) | 1600 sets |
3. Installation
Outline (Unit : mm)
