Integrated R404a Cold Storage Room , Low Temperature Cold Room Fresh Keeping

Integrated R404a Cold Storage Room , Low Temperature Cold Room Fresh Keeping

Mobile Cold Storage Features

1). Polyurethane insulation board design , the main steel structure to faciliate consturction.

2). Portable hinged and sliding doors, and out of cold storage more convenient , easy to operate.

3). Water defrosting evaporator defrost faster , save operating cost.

4).Cold rooms door with anit-shock protection , an increase of reliability.

5). Room temperature -45 to 15 degree.

Main Components and Features of Cold Room:

1.Flexible for construction different sizesmade of modular fabrication with polyurethane insulation

with different dimensions.

2.allows for easy assembly and disassembly

3.Panel thickness: 50mm-200mm (for -45 to 5 Celsius degree).

4.According to different temperature range, cold room can be divided degree Celsius cold room

Cold storage refrigeration unit

1) Condensing unit: , Copeland, Maneurop, Frashcold..

2) Insulation Panel : PU, EPS

3)Other accessories:world-famous brands, like Danfoss, Castle, Electrical controller LG ...

Germany brand compressor condensing unit

Cold storage panels

Cold Room insulation panel use 100% polyurethane insulation panel, density about

40~45kg/m3, with gasket,flame retardant , panel thickness : 50mm ~200mm, standard

width of panel is 960mm

Cold storage door

1).Swing door and sliding door for choice.

2).Swing door : manual opended , automatic,etc.

3).Door board made with special pressing technology PU material.

4).Door frame : color steel or stainless steel.

5).Surface material : color steel or stainless steel with protecting film.

Cold storage control box

ust a start press, you can control the system automatically, without man-made operation.

When the room temperature cools to lower limit of the set temperature, the compressor

and air cooled will stop to work automatically; when the room temperature rises to uper

limit of the set temperature , the compressor and air cooled will start to work automatically.

Cold storage air cooler

Celling air cooler used to cool the air down inside the cold room

containerized cold room

Guangzhou Icesource Co., Ltd. (trademark CBFI), a pioneer in the large-scale freon refrigeration and ice making equipment industry, a large ice plant and cold storage engineering solution service provider, is an innovative and entrepreneurial high-tech enterprise that integrates research, design, manufacture, sales, and after-sales service of a large-scale edible ice making equipment, large-scale industrial ice making equipment, high-end commercial ice maker, complete ice making system and small and large cold storage project. The main products are various kinds of ice making machine(direct-cooling block ice machine, block ice machine, tube ice machine, cube ice machine, flake ice machine, plate ice machine, pure ice machine and fully automated ice plant). Products are widely used in food, fishery, retail, fruits and vegetables, aquatic products, chemicals, medical, construction, minerals and other fields for cooling, storage and preservation.

Introduction to CBFI Company

Certifications

Enteprise Honor

Our partners

Packing process

Our Factory

CBFI Quality Management Department

CBFI Quality Management Department is an important control method for processing quality. It equipped with the most advanced inspection equipments The professional control devices,it can provide accurate reference data to choose the most suitable material and accessories, which also effectively control parts quality. Besides, it also provides digital information for engineers and quality controller to determine feasibility for spare parts after processing.

This is the working processing of quality control.

Chooing steady quality supplier. After purchasing raw material, duing testing if it is proved well, then we will arrange these eligible matrial that come into warehouse.

When the machine finish fixing and come into testing working conditon. Every worker will be responsible for their equipment. They will give out fact testing date and results.After proving testing date is accord with delivery standard. Then CBFI Quality Management Department will allow these equipment that go to packing department and waiting for cleaning and packing.

Before delivery, CBFI Quality Management Department should check all mark and packing conditon. If it is prove it is accord with exporting standard and customer's requirement. Then they will allow these equipment come into fininshed product area.

Of course CBFI Quality Management Department have the right to make sample testing for every production step to make sure product quality.

CBFI means Customer Benefits From Icesource. We will take care of product quality.
