Steel Security Door Frame Roll Forming Machine with 14 Steps , 85 mm Effective Width

Categories Door Frame Roll Forming Machine
Brand Name: HC
Model Number: HC146/196
Certification: ISO
Place of Origin: Botou Hebei China
MOQ: 1set
Price: 12000-29000USD
Payment Terms: 30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment
Supply Ability: 20 sets/month
Delivery Time: 30days
Packaging Details: Main machine is nude,the computer control box is packed by carton box
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Steel Security Door Frame Roll Forming Machine with 14 Steps , 85 mm Effective Width

Steel Security Door Frame Roll Forming Machine with 14 Steps , 85 mm Effective Width

Specifications

Door roll forming machine: material for producing roofing:

Normal colored painted and galvanized sheets with yield strength 245, 345MP


a. Main Accessories:


(1) Main Forming Machine;

(2) 3 Tons Manual Uncoiler;;

(3) Hydraulic System;

(4) PLC Computer Controlling System with Touch Screen

(Brand: Delta for PLC, touchingscreen,encorder and frequency changer);

(5) Hydraulic Forming Cutter;

(6) Run Out Tables(3 Units);

(7) Operation Manual.


b.Main Technical Data


Size4000*900*1400mm
Weight2500KGS
Hydraulic Motor Power4KW
Effective Width85mm
Material Width136mm
Forming Steps14 steps
Processing Speed8-12m/min
Voltage380V/50HZ/3PH
Material of principal axishigh grade 45# forged steel
Material of rollerGCr15 with hard chrome plating
Material of bladeCr12 mould steel with quenched treatment 60-62°C
Material for frame of machineFine welded structural steel
Sprocket wheel45 steel high-frequencies quench

Material for producing roofing: normal colored painted and galvanized sheets with strength 245, 345MPA;

Warranty: 1 year and life-long maintain;

Installation and debugging: We will send professional engineer to make installation and debugging, Buyer pay our engineer each one 50 USD/day, and provide accommodation, food and the round-trip ticket fee.

Installation Days: about 5-7 days

Installation and Training:


If buyers visit our factory and check the machine, we will teach you how to install and use the machine,

and also train your workers/technician face to face.
Without visiting,we will send you user manual and video to teach you to install and operate.
If buyer needs our technician to go to your local factory,please arrange board and lodging and other necessary things.
