10 Mbps Data Line 1- Port Data Surge Protector With IEC61643-21 Standard

Name: 10 Mbps Data Line 1 Port Data Surge Protector With IEC6164321 Standard
Brand: BRITEC
Price: 1 USD

10 Mbps Data Line 1- Port Data Surge Protector With IEC61643-21 Standard

Categories	Data Surge Protector
Brand Name:	BRITEC
Model Number:	BRGI-2L-6 1port
Certification:	CE
Place of Origin:	Zhejiang, China (Mainland)
MOQ:	200 Piece/Pieces
Payment Terms:	T/T
Supply Ability:	50000 Piece/Pieces per Month
Delivery Time:	Shipped in 15-30 days after payment
Packaging Details:	EXPORT PACKING
Standards:	IEC 61643-21
Item Name:	Rs485 surge protection device
Material:	aluminium alloy
Un:	6V
Port:	1 port
Tu:	-40℃-80℃

Contact Now

Add to Cart

Company Info.

Britec Electric Co., Ltd.

Verified Supplier

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

10 Mbps Data Line 1- Port Data Surge Protector With IEC61643-21 Standard

10 Mbps Data Line 1-Port Data Surge Protector IEC61643-21 Standard

Characteristics:

• Compatible with 6V nominal voltage.

• 5kA surge discharge current.

• 10 Mbps data rate.

• Grounding is accomplished via a ground wire.

Product Details:

	BRGI-2L-6 1port
Test standards	IEC 61643-21
Nominal voltage Un	6V
Max. continuous operating d.c. voltage Uc	8V
Max. continuous operating a.c. voltage Uc	5V
Nominal current IL	0.5A
C2 Nominal discharge current (8/20us) per line In	5kA
Voltage protection level [line-line] Up	≤30V
Voltage protection level [line-PG] Up	≤600V
Response time [line-line] tA	≤1ns
Response time [line-PG] tA	≤100ns
Operating temperature range Tu	-40℃…+80℃
Connection input / output	Terminal Block
Bandwidth	10 Mbps
Insertion Loss	≤0.3dB
Enclosure material	aluminium alloy
Degree of protection	IP20

Technology characteristic:

Application:

• Protect expensive equipment against surges and transients entering a building on exposed

transmission lines.

• Protect electrical devices from voltage spikes.

• Protect high-speed communication network from lightning over-voltage, transient over-voltage and

static discharge.

Advantage:

• Fast energy absorption when over-voltage occurs.

• Advanced manufacturing process.

• Excellent performance on discharge current.

• Fast response time.

• Professional manufacturer.

Factory:

Certification:

FAQ:

Q1. Are you a trading company or manufacturer?

A: Manufacturer with factory!

Q2. What kinds of products do you produce?
A: It covers AC surge protection, DC lightning protection, data surge protector, LED lightning

arrester,etc.

Q3.Is customized available?
A: Yes, please offer your required specs.

Q4. Do you accept OEM service?
A: YES!

Q5. What's your Delivery Time?
A: Normally 15-30days
