CNC Control System Sealant Extruder With 8 Axis Servo Motors For Triple Glass

Categories Sealant Extruder
Brand Name: LIJIANG GLASS
Model Number: LJTJ2540
Certification: CE
Place of Origin: JINAN,CHINA
MOQ: 1 set
Price: Negotiable
Supply Ability: 50 sets per year
Delivery Time: 60 days
Packaging Details: Container
Production name: Insulating glass sealant extruder machine
Min glass size: 300mm*300mm
Max glass size: 2500mm*4000mm
Stepped glass: Available
Control system: Servo motor
Glass thickness: 12- 56mm
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

CNC Control System Sealant Extruder With 8 Axis Servo Motors For Triple Glass

CNC Control System Sealant Extruder With 8-axis Servo Motors For Triple Glass


Introduction :


Applying CNC control system with 8-axis servo motors movement to reach fast and continous sealing for insulating glass.
Servo motor drive hydraulic pump to control accurate calculation and rate of flow to get precise ratio.
Automatically and accurately check sealing depth and spacer width, control sealing quantity.Automatic corner trimming function.

Parameters:

Max.glass size2500*4000mm
Min.glass size300*300mm
Glass thickness12-56mm
Working speed5-40m/min
Air pressure0.5-0.7MPa
Squeeze pressure32MPa
Voltage power380V 12kw
Overall dimension8700*2000*3500mm

Features:


1. High automation, suitable for glass deep processing enterprise to use.


2. Whole machine adopt man-machine interface, the operation is more convenient and intuitionistic with the simplified thinking design interface.


3. The glass edge and corner is full without air bubbles, smooth surface.


4. Using two sets of independent sealant supply system(including the mixing device), two kinds of sealants switch in one-key operation easilly.


5. The third section can prestore glass to improve the efficiency effectively. Support three layer glass sealant.


6. Servo control system adopts world famous brand(Japan Anchuan), the performance is stable.


7. Synchronous belt transmission to make the glass being transferren smoothly with accurate positioning
