2mm Thickness 2OZ ENIG Aluminum PCB for Power

2mm Thickness 2OZ ENIG Aluminum PCB for Power

♦ What is Aluminum PCB?

♦ Features of Aluminum PCB

• • Excellent heat dissipation performance: The core advantage of aluminum-based PCBs is the high thermal conductivity of the substrate itself (the thermal conductivity of aluminum is usually 150~240 W/(m·K), much higher than the 0.3~0.5 W/(m·K) of ordinary FR-4 epoxy resin boards). Heat can be quickly transferred to the housing or heat sink through the aluminum substrate to avoid local overheating.
  • ​​Good electrical performance: The dielectric constant of the insulating layer is usually 3~5 (lower than 4~5 of FR-4, but higher than ceramic substrate), which is suitable for medium and high frequency circuits (but high frequency applications still require ceramic substrates).
  • High rigidity: The mechanical strength of aluminum substrate is better than that of organic substrates such as FR-4, and it has strong resistance to bending and vibration, making it suitable for scenarios with high requirements for structural stability (such as automobiles and industrial equipment).

♦ Applications of Aluminum PCB

• • ​​LED lighting: Solve the problem of high heating of LED lamp beads (such as street lights, spotlights, and car headlights) to ensure stable lighting effect and life.
  • ​​Power supply and power devices: Adapt to high-current devices such as switching power supplies, inverters, and frequency converters, and quickly dissipate the heat of components such as IGBTs and MOS tubes.
  • ​​Automotive electronics: Used in on-board chargers (OBCs), DC-DC converters, and car light drive modules to cope with high temperature environments in the engine compartment.
  • ​​​​Industrial control: Heat dissipation and circuit integration of high-voltage equipment such as servo drives and PLC controllers.

♦ Technical Parameters

♦ One-Stop PCBs Solution

PCB Prototype	Felx PCB	Rigid-Flex PCB	Ceramic PCB
Heavy Copper PCB	HDI PCB	High Frequency PCB	High TG PCB

♦ Advantages of DQS Team

1. On-time Delivery:

• • Owned PCBA factories 15,000 ㎡
  • 13 fully automatic SMT lines
  • 4 DIP assembly lines

2. Quality Guaranteed:

• • IATF, ISO, IPC, UL standards
  • Online SPI, AOI, X-Ray Inspection
  • The qualified rate of products reach 99.9%

3. Premium Service:

• • 24H reply your inquiry
  • Perfect after-sales service system
  • From prototype to mass production

DQS Electronic is located in Shenzhen, focusing on PCB Layout Design, PCB Fabrication, Electronic Components Sourcing, SMT, PCB Assembly and Testing. We are a one-stop EMS electronic manufacturing company committed to providing global customers with rapid prototyping and mass production.

Our products include single, double, multi, high frequency, aluminum base, copper base, FR-4 and other high precision circuit boards.

We have over 10 years of experience in serving many domestic and foreign brand customers in a wide range of fields such as Medical, Automotive, Industrial Automation, Artificial Intelligence, Smart Home, Security, Power and Communications, etc..
