Fast Production Automatic Chain Link Fencing Machine Auto Cut 80-150㎡/Hours

Fast-Production Automatic Chain Link Fence Machine Auto-Cut

1.Chain Link Fence Machine Introduction:

1: The automatic single wire chain link fence machine is our company's advantage product. Through cooperation with German company, we have improved the technology and greatly improved the mechanical quality and output.

2:This machine is mainly used for animal husbandry fence. mechanical equipment protection mesh, highway guardrail, stadium fence,road green belt protection mesh. It can also be used in handicraft manufacturing.

3:This machine can make galvanized wire, low carbon steel wire, aluminum alloy wire, PVC wire, etc. the mesh surface is smooth,beautiful, not easy to corrosion, long service life, beautiful and practical.

2.Mechanical motor configuration.

Main servo motor : 3.8 kw

Cutting knife motor : 0.75 kw

Barrier motor : 0.75 kw

Positioning needle motor : 0.75 kw

Pull mesh motor : 0.75 kw

Mesh edge motor : 0.75 kw X 2

Roll mesh motor 0.75 kw

Mesh width adjust motor : 0.12 kw Pump motor : 0.04 kw

3.Mechanical advantages:

1.Automatic adjustment of chain link fence mesh width.

2.The machine will give an alarm when the coil is disordered.

3.The cutter device is also equipped with a brake system for more accurate positioning.

4.The machine is equipped with two sets of edge system ( hook edge and twisted edge).

5.The mesh rolling system is equipped with brake device, so the wire mesh will not reverse.

6.The connecting line uses aviation plug, which is convenient for customers to install machinery.

7 .The machine adopts aluminum alloy cantilever box for operation, which is simple and convenient.

8.The machine is equipped with remote control device, which is convenient for employees to operate the machine.

4. Machine Specification

Model	APB3000
Mesh width	500-3000 mm (can be customized)
Mesh size	25-100 mm
Wire diameter	1.4-4.0 mm
Production speed	80-150 m²/h
Mesh edge	Hook edge and twisted edge ( 2 set edge system)
Machine weight	3500 KG
Mechanical dimension	580036001800 mm

5.Detailed images:
