| Categories | Steel Tin Plate |
|---|---|
| Brand Name: | Wuxi Talat |
| Model Number: | MR |
| Certification: | manufacture certificate |
| Place of Origin: | China |
| MOQ: | 5 tons |
| Price: | negotiated |
| Payment Terms: | L/C,T/T,Western Union |
| Supply Ability: | 10000tons |
| Delivery Time: | 15-20days |
| Packaging Details: | standard seaworthy package |
| Thickness: | 0.16mm - 0.50mm |
| Tin Coating: | 1.1/1.1, 2.8/2.8, 5.6/5.6, 8.4/8.4 |
| Price Term: | CIF CFR FOB EX-WORK |
| Surface Treatment: | Coated |
| Coil Weight: | 3-5 Tons or as requirment |
| Usage: | chemical can,food packaging |
| Payment: | L/C, T/T, Western Union |
| Application: | EOE; oil cans; food can |
| Company Info. |
| Wuxi Talat Steel Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
Premium ETP tinplate coil and sheet with excellent corrosion resistance, weldability, and coating performance. Ideal for food cans, lids, and industrial packaging. Custom sizes & fast delivery.
ETP Tinplate (Electrolytic Tinplate) is a cold-rolled low carbon steel coated with a thin layer of tin on both sides. It combines the strength of steel with the corrosion resistance of tin, making it one of the most widely used materials in metal packaging.Our tinplate sheet and tinplate coil are designed for high-performance applications such as food cans, beverage containers, and industrial packaging.
| Specification | |
| Thickness: 0.15mm~0.50mm | Width:700mm~1050mm |
| Temper | |
| Single Reduced:T1, T2, T3, T4, T5 | Double Reduced: DR8, DR9, DR10 |
| Surface Finish: Bright, Stone, Silver, Matte | |
| Anneal: CA/ BA | Material: MR/ SPCC |
| Tin coating: | |
| Equal Tin-coating:1.1/1.1, 2.0/2.0, 2.8/2.8, 5.6/5.6 | Different Tin-caoting: 2.0/1.1, 2.8/1.1, 2.8/2.0, 5.6/2.0, 5.6/2.8 |
Standard
| Temper | ||||
Standard | Japanese Standard | Chiness Standard | European Standard | American Standard |
| JIS3303-2002 | GB/T2520-2000 | DIN EN 10203-1991 | ASTM623M-2002 | |
Single-Reduced | T1 | TH50+SE | TS230 | T1(T49) |
| T2 | TH52+SE | TS245 | T1(T53) | |
| T2.5 | TH55+SE | TS260 | T2.5(T55) | |
| T3 | TH57+SE | TS275 | T3(T57) | |
| T4 | TH61+SE | TH415 | T4(T61) | |
| T5 | TH65+SE | TH435 | T5(T65) | |
Double-Reduced | DR7 | H71+SE | TH520 | DR7 (T71) |
| DR8 | H73+SE | TH550 | DR8(T73) | |
| DR9 | H76+SE | TH620 | DR9(T76) | |
| Temper Grade | Hardness (HR30Tm) | Yield Strength (MPa) |
|---|---|---|
| T-1 | 49±3 | 330 |
| T-2 | 53±3 | 350 |
| T-3 | 57±3 | 370 |
| T-4 | 61±3 | 415 |
| T-5 | 65±3 | 450 |
| T-6 | 70±3 | 530 |
| DR-7M | 71±5 | 520 |
| DR-8 | 73±5 | 550 |
| DR-8M | 73±5 | 580 |
| DR-9 | 76±5 | 620 |
| DR-9M | 77±5 | 660 |
| DR-10 | 80±5 | 690 |
| Former Coating Designation | Nominal Coating Weight (g/m²) | Minimum Average Coating Weight (g/m²) |
|---|---|---|
| 10# | 1.1/1.1 | 0.9/0.9 |
| 20# | 2.2/2.2 | 1.8/1.8 |
| 25# | 2.8/2.8 | 2.5/2.5 |
| 50# | 5.6/5.6 | 5.2/5.2 |
| 75# | 8.4/8.4 | 7.8/7.8 |
| 100# | 11.2/11.2 | 10.1/10.1 |
| 25#/10# | 2.8/1.1 | 2.5/0.9 |
| 50#/10# | 5.6/1.1 | 5.2/0.9 |
| 75#/25# | 5.6/2.8 | 5.2/2.5 |
| 75#/50# | 8.4/2.8 | 7.8/2.5 |
| 75#/50# | 8.4/5.6 | 7.8/5.2 |
| 100#/25# | 11.2/2.8 | 10.1/2.5 |
| 100#/50# | 11.2/5.6 | 10.1/5.2 |
| 100#/75# | 11.2/8.4 | 10.1/7.8 |
| 125#/50# | 15.1/5.6 | 13.9/5.2 |
| Surface Finish | ||
| Classification | Symbol | Specific Feature |
| Bright Finish | B | A luster finish provided by a flow-melted tin coating on a smoothly finished steel based with grindstone-pattern. |
| Stone Finish | R | A luster finish provided by a flow-melted tin coating on a steel base characterized by a directional grindstone-pattern. |
| Silver Finish | S | A luster finish provided by a flow-melted tin coating on a coarse dull-finished steel base. |
| Matte Finish | M | A dull finish usually provided by an unflow-melted tin coating on a dull finished steel base. |
Tinplate is primarily used for packaging foodstuffs and beverages, but it is also used in containers for oils, grease, paints, polishes, chemicals and many other products. Aerosol containers and caps and closures are also made from ETP.
|
