| Categories | High Flow Cartridge Filter Housing |
|---|---|
| Brand Name: | YATE |
| Certification: | ISO9001,CE |
| Place of Origin: | Shandong, China |
| MOQ: | 1 |
| Price: | Negotiable |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union |
| Supply Ability: | 30 set/set per day |
| Delivery Time: | 7 days |
| Flow Rate: | customized |
| condition: | New |
| Maximum pressure: | customized |
| Particle Size: | 0.1um |
| warranty: | 1 Year |
| weight (kg): | 40 |
| Product name: | Stainless Steel security precision filter |
| Application: | White Rice Fruit Wine Grape Wine |
| Design: | Vertical type |
| Material: | Stainless Steel 304/316L |
| Usage: | Liquild Filter |
| Size: | Customized Size |
| Working Pressure: | 0.6Mpa |
| Filter element Material: | PP/PE |
| Min. Filtration Precision: | 0.1 μm |
| Name: | Cartridge Water Filter Housing |
| Company Info. |
| Shandong Yate Filter Material Co., LTD |
| Verified Supplier |
| View Contact Details |
| Product List |


Model | Filter element | Filter element Qty | Connection | Max. Flow (m³/h) | Working pressure(MPa) |
YT-10*1 | 10” | 1 | DN20 | 0.5 | 0.5-1.6 |
YT-20*3 | 20” | 3 | DN25 | 3 | 0.5-1.6 |
YT-20*10 | 20” | 10 | DN50 | 10 | 0.5-1.6 |
YT-20*7 | 20” | 7 | DN40 | 7 | 0.5-1.6 |
YT-30*5 | 30” | 5 | DN25 | 7.5 | 0.5-1.6 |
YT-30*11 | 30” | 11 | DN40 | 16.5 | 0.5-1.6 |







|
