Custom CNC Machined EPS/EPP Aluminum Alloy Lost Foam Mold Styrofoam Tooling for LFC Casting Patterns, OEM

This custom CNC-machined EPS/EPP aluminum alloy lost foam mold is engineered to produce expendable foam patterns for the lost foam casting (LFC) process. The cavity is machined according to the customer’s foam pattern drawing, with steam and cooling channels arranged to support uniform bead fusion and stable pattern release. The tool can be configured in single or multi-cavity layouts and is applied to foam pattern production for automotive, machine tool, and industrial castings. From design review to trial molding, the mold is developed around the dimensional and surface requirements of the downstream metal pouring operation.

Specifications

Mould Features

1. Customized Cavity Geometry
   The cavity is machined to match the customer’s foam pattern drawing, with draft, parting, and core details adapted to the lost foam casting route.

2. Aluminum Alloy Tool Body
   The mold body is made from aluminum alloy, offering rapid thermal response, resistance to steam exposure, and manageable weight for handling and setup.

3. Steam and Cooling Integration
   Internal channels are arranged to deliver steam for bead expansion and water for cooling, helping maintain consistent foam pattern density and dimensions.

4. Venting and Release Design
   Vent paths and ejector provisions are incorporated to support complete cavity fill and clean removal of fragile foam patterns.

5. Modular Cavity Arrangement
   The tool can be built with single or multiple cavities, using replaceable inserts and split-block construction to simplify maintenance and future geometry changes.

Applications

• Automotive Casting Patterns
  Foam tooling for producing expendable patterns used in engine, transmission, and structural castings.

• Machine Tool Bed Patterns
  Molds for foam patterns applied to machine tool beds, bases, and columns.

• Industrial Pump and Valve Patterns
  Tooling for foam patterns used in pump bodies, valve housings, and compressor components.

• Heavy Machinery Component Patterns
  Molds for foam patterns applied to construction, agricultural, and mining equipment castings.

• Prototype and Trial Casting Patterns
  Tooling for development projects, process validation, and small-batch production runs.

Manufacture Process
1. Review the part design,drawings and quality standard from clients.
2. Mould and Tooling design & manufacturing
3. Mould and Tooling testing & confirm the sample
4. Die casting raw castings
5. Surface treatment: Trimming,Deburring, polishing, cleaning, passivation & power coating and other requirement from Customer
6. Precision machining: CNC lathes, milling, drilling, grinding etc
7. Full Inspection
8. Packing
9. Delivery

Packing & Shipping

Flexible Shipping Options: We understand that every customer has unique needs. That's why we offer flexible shipping options, including air freight, sea freight, and expedited delivery services. Our team will work with you to determine the most cost-effective and efficient shipping method based on your timeline and budget.

Our Advantages
1. We are the biggest lost foam mould manufacturer in China, we focus on high challenge lost foam mould and we have large gantry machining centers,30 sets imported high speed machining center,more than 40 sets general machine tool equipment;
2. We have 36 senior mould designers, to ensure reasonable / safety / high efficiency mould design and ensure the fast mould delivery and rational mould structure, make the process more safer and the production efficiency more higher;
3. We using numerical control machine tool to manufacture the mould cavities, to ensure a even thickness ;
4. We using ZL104 Aluminium to casting the mould, to manufacture a high strength mould;
5. For the big mould, we using Ø22*1 copper tube as cooling pipe, with water spray system, to get a nice cooling effect;
6. We Have (TEF10N) coating on the mould surface, it can reduce the friction, anti water/static electricity/acid-base/high-temperature, with this we can ensure the pattern has smooth surface without distrotion, and easy to demould;
7. All the screws we using stainless steel screw, easy to disassemble during maintenance;
8. For the big mould chest, we using 18-20mm thick wrought aluminium plate, to offer high strenght cavity ;
9. For the complex mould which is difficult to demould, we can manufacture the automaitc mould with take out device ;
10. We produce the pattern sample to customer after finish the mould, when the pattern was qualified, then we do exceptance job for the mould ;
11. We have the Hexagon coordinate measuring instrument imported from the Switzerland to have a test make sure our mould qualified.
