HK2M-H209 Wide Dynamic 1080p Wide-Angle Face Recognition USB Camera Module FOV 95°

Categories	Face Recognition Camera Module
Brand Name:	Shi Zun
Model Number:	HK2M-H209
Place of Origin:	China
MOQ:	Negotiable
Price:	Negotiable
Payment Terms:	T/T
Supply Ability:	100+pcs+day
Delivery Time:	10 working days
Packaging Details:	38mmx 38mmx 17.6mm
Photosensitive chip:	RGB CMOS 1/2.7"
Pixel Size:	3.0μm x3.0μm
SNR max:	TBD dB
Max Dynamic range:	90 dB
Minimum illumination:	0.1Lux at F12
F/No:	2.4
EFL:	2.9mm
FOV:	95°
IR:	650±10nm
Lens Construction:	2G2P+IR
Maximum resolution and frame rate:	1920* 1080(30ps)
Other optional resolution ratio:	640* 480 (30fps), 800* 600(30fps), 1280* 720(30fps)
Support format:	YUV / MJPG
USB power supply voltage:	5V±5%
Connect the interface:	1* USB-5pin-1.0mm
Interface speed:	480mb/s
Operating systemrequest:	WinXP, Win7, Linux or Vista and android4.1
Power Consumption:	Regular work: 0.7W
storage temperature:	0°C to 50°C
Working temperature:	-10°C to+60°
structure size:	38mmx 38mmx 17.6mm

Contact Now

Add to Cart

Company Info.

Shenzhen Jupin Technology Co., Ltd.

View Contact Details

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

HK2M-H209 Wide Dynamic 1080p Wide-Angle Face Recognition USB Camera Module FOV 95°

HK2M-H209 Face Recognition USB Camera Module Features:

USB 2.0 Interface
Suitable for Face Feature Detection
Plug and Play
1080P High-Definition Camera
Frame Rate Up to 30 FPS, CE Ensures Maximum Image Clarity and Detail
Suitable for Various Industrial Control, Intelligent Self-Service Terminals, Face Recognition Access Control, Security Equipment, and Other Scenarios
1/2.7 Large Size SENSOR
Backlight Compensation
Software Wide Dynamic Range

HK2M-H209 Face Recognition USB Camera Module Parameter:

Connect the interface:	1* USB-5pin-1.0mm
Interface speed:	480mb/s
Maximum resolution and frame rate:	1920* 1080(30ps)
Other optional resolution ratio:	640* 480 (30fps), 800* 600(30fps), 1280* 720(30fps)
Support format:	YUV/ MJPG
Max Dynamic range:	90 dB
F/No:	2.4
EFL:	2.9mm
FOV:	95°
Lens Construction:	2G2P+IR
Power Consumption:	Regular work: 0.7W
Operating systemrequest:	WinXP, Win7, Linux or Vista and android4.1
