| Categories | Compact CMOS Spectrometer |
|---|---|
| Brand Name: | JINSP |
| Model Number: | SR50C |
| Certification: | CE |
| Place of Origin: | CHINA |
| MOQ: | 1 |
| Price: | Negotiable |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100 PCS/70-90 days |
| Delivery Time: | 30-50working days |
| Packaging Details: | Customized Packaging |
| Weight: | 220g |
| Fiber Input Interface: | SMA-905, free space |
| Fiber Type: | Single mode or multimode |
| Detector Chip Type: | Linear array CMOS, Hamamatsu S11639 |
| Operating Humidity: | ＜90%RH (no condensation) |
| Pixel Size: | 14μm *200μm |
| Pintegration Time: | 1ms-60s |
| Model: | SR50C Fiber spectrometer |
| Company Info. |
| JINSP Company Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
With an effective pixel of 2048 and a linear array CMOS chip type, specifically the Hamamatsu S11639, this Fiber Spectrometer can accurately detect and measure the intensity of light across a broad wavelength range. It also features a compact design, measuring only 76mm*65mm*36mm, making it easy to use and carry around.
The Universal Compact Fiber Spectrometer is equipped with a USB 2.0 or Serial Port data output interface, enabling users to easily transfer data to a computer or other devices. This feature ensures that users can analyze and interpret data in real-time, allowing for a more efficient and effective data collection process.
| No | Item | Description |
| 1 | Name | SR50C Fiber Optic Spectrometer |
| 2 | Chip Type | Linear array CMOS, Hamamatsu S11639 |
| 3 | Effective Pixel | 2048 |
| 4 | Sensing Area | 28.7mm *0.2mm |
| 5 | Optical Design | M Type C-T light path |
| 6 | Numerical Aperture | 0.14 |
| 7 | Entrance Slit Width | 10μm, 25μm, 50μm, 100μm, 200μm (customizable) |
| 8 | Dimensions | 76mm*65mm*36mm |
| 9 | Weight | 220g |
The JINSP SR75C is suitable for a wide range of applications, including but not limited to:
The product has an effective pixel of 2048 and a weight of 220g, making it lightweight and easy to carry around. It operates in a wavelength range of 200nm to 1100nm, with support for customizing. The Fiber Connector used is FC/PC, which is compatible with multiple fiber types.
The JINSP SR75C has an operating humidity of less than 90% RH (no condensation), making it suitable for use in various environmental conditions.
Q1: What is the brand name of this product?
A1: The brand name of this product is JINSP.
Q2: What is the model number of this spectrometer?
A2: The model number of this spectrometer is SR75C.
Q3: Does this product have any certification?
A3: Yes, this product has CE certification.
Q4: Where is this spectrometer made?
A4: This spectrometer is made in China.
|
