| Categories | High Frequency Transformer |
|---|---|
| Model Number: | EE19 |
| Type: | high frequency transformer |
| Place of Origin: | Guangdong, China |
| Brand Name: | Chipsen |
| D/C: | AC/AC, AC/DC |
| Supplier Type: | Manufacturer |
| Application: | Energy product, stepping up |
| Brand: | Chipsen |
| Package Type: | NO |
| Operating Temperature: | -20~180 |
| Tolerance: | 10% |
| Package / Case: | No |
| Turns Ratio: | 1:2 |
| Output Voltage: | 24V 48V 60V 120V 240V |
| Output Power: | 100W |
| Output Current: | 1.6A |
| Certification: | ISO9001:2015, IATF16949:2016, U/L, RoHS, CQC |
| R&D Cost: | Free design service |
| Warranty: | 5 years |
| Electronic Solution: | One-stop Solution |
| Sample Cost: | Free samples available |
| MOQ: | 1000 pieces |
| Price: | CN¥6.68/pieces 1000-9999 pieces |
Model No. | High frequency transformer EE16 | |
Working Frequency Range | 1KHz-1MHz | |
Output Power | 1W-3000W | |
Output Voltage | 0.5V-15000V | |
Output Current | 0.01A-100A | |
Storage Temperature | +5℃ to +95℃ | |
Working Temperature | -40℃ to +125℃ | |
Storage Humidity | 30% to 70% | |
Certifications | ISO9001:2015, ISO14001:2015, IATF16949, UL/cUL, ROHS, REACH, CQC | |
Designing Information | operating frequency | |
circuit topology | ||
input voltage range | ||
output power (V/A) | ||
mounting dimensions | ||
safety requirements | ||
product application |
|
