Automatic Rotary Die Cutting Machine for Adhesive Labels & Paper, 70m/min Speed

Categories Label Die Cutting Machine
Brand Name: FOCUS
Model Number: FM-320&FM-420
Certification: SGS, FSC,ISO
Place of Origin: China
MOQ: 1
Price: 8500
Payment Terms: L/C, T/T
Delivery Time: 30-50 days
Packaging Details: Sea-Worthy Wooden Case
Die cutting speed: 70m/min
Working width: 0-420mm
Maximum unwinding diameter: 500mm
Maximum winding diameter: 480mm
Die Cut Length: 178-470mm(7" - 18,5")
Machine size: 1.57mx1.02mx1.61m
Machine weight: 1800kgs
Voltage: 220V 50HZ
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Automatic Rotary Die Cutting Machine for Adhesive Labels & Paper, 70m/min Speed

Automatic Rotary Die Cutting Machine for Adhesive Labels & Paper, 70m/min Speed
Key Specifications
AttributeValue
Die cutting speed70m/min
Working width0-420mm
Maximum unwinding diameter500mm
Maximum winding diameter480mm
Die Cut Length178-470mm (7" - 18.5")
Machine size1.57m x 1.02m x 1.61m
Machine weight1800kgs
Voltage220V 50HZ
Product Overview

This professional die-cutting equipment serves the field of paper precision processing, focusing on solving the cutting and slitting needs of roll label materials. Through integrated design, it realizes the full process automation from printing to finished product winding, and its intelligent control system significantly improves operational efficiency.

Machine Features
  • High-precision circular die-cutting system
  • Suitable for blank self-adhesive labels
  • Die cutting and slitting can be done at same time
  • Automatic meter counting, automatic shutdown, photoelectric eye correction
  • Compact structure, fast speed, high efficiency, simple operation and stable operation
Technical Parameters
ModelFM-320FM-420
Die cutting speed70m/min70m/min
Working width0-320mm0-420mm
Maximum unwinding diameter500mm500mm
Maximum winding diameter480mm480mm
Die Cut Length178-470mm (7" - 18.5")178-470mm (7" - 18.5")
Machine size1.57m x 1.02m x 1.61m1.57m x 1.12m x 1.61m
Machine weight1200kgs1800kgs
Voltage220V 50HZ220V 50HZ
Standard Configuration
  • Slitting device
  • One 3-inch unwinding air shaft
  • Two 3-inch rewinding air shafts
  • Counting/meter counter
  • Two photoelectric eyes for deviation correction
  • 8 round knives
  • One magnetic powder brake, two clutches
Applications

Suitable for die-cutting and slitting of self-adhesive labels, paper, film (PET, PC, PE), non-woven fabric, foam, double-sided tape, copper foil/aluminum foil and various roll materials. Widely used in printing, packaging, 3C electronics, leather, clothing, plastic and other industries.

Product Images
Die-cutting platform (die-cutting knives are not included in the price)
Quality Automatic Rotary Die Cutting Machine for Adhesive Labels & Paper, 70m/min Speed for sale
